Digital Multifunctional System
31 ppm Monochrome Digital Multifunctional System BP-20M31 Compare
31 ppm Colour

A Speedy Network-Ready MFP for Upwardly Mobile Office



BP-20M31 is a very flexible compact A3 Monochrome MFP in the office with optional  Wireless LAN. The MFP is designed to streamline your workflow, both in the office and outside. BP-20M31 achieves Faster Result with Copy/Network Print (PCL)/Network Scan functions with optional Wireless LAN and standard RSPF (Reversing Single Pass Feeder).



Users can enjoy Easier Connection with Wireless Connectivity, Link with Mobile Devices, and User Authentication which restricts others by requiring password. User Authentication limits other users from printing and photocopying which works as Good Cost Saving Factor.



"Program" on display and 2 Scanner Program Keys are ready for easy operability. Users can register common functions and settings for easy, one-touch recall.



Faster Result, Easier Connection, and Greater Use, this is the MFP to choose for your business.

WHERE TO BUY


GENERAL (-)
Type Desktop
Engine speed (colour & B/W) A4 (8 1/2" x 11")*1: Max. 31/28/24/22 ppm A3 (11" x 17"): Max. 17/17/12 (11)/12 (11) ppm
Control panel display 5-line LCD
Paper size Max. A3 (11" x 17"), min. A6*2 (5 1/2" x 8 1/2")
Paper capacity(80 g/m²) [BP-20M31/20M28] Standard: 1,100 sheets (2 x 500-sheet tray and 100-sheet multi bypass tray) Maximum: 2,100 sheets (1,100 sheets & optional 2 x 500-sheet tray) [BP-20M24/20M22] Standard: 350 sheets (250-sheet tray and 100-sheet multi bypass tray) Maximum: 1,850 sheets (350 sheets & optional 3 x 500-sheet tray)
Paper weight Tray 1: 60 g/m2 to 105 g/m2 (16 lbs bond to 28 lbs bond) Trays 2–4: 60 g/m2 to 200 g/m2 (16 lbs bond to 110 lbs index) Multi bypass tray: 55 g/m2 to 200 g/m2 (13 lbs bond to 110 lbs index)
Warm-up time BP-20M31/20M28: 20 sec. BP-20M24/20M22: 25 sec.
Memory 1 GB (copy/print shared)
Power requeirements Rated local AC voltage ±10%, 50/60 Hz
Power consumption BP-20M31/20M28: Max. 1.45 kW BP-20M24/20M22: Max. 1.2 kW
Dimensions(W×D×H) including document cover BP-20M31/20M28: 599 x 608 x 743 mm (23 19/32" x 23 15/16" x 29 17/64") BP-20M24/20M22: 599 x 608 x 643 mm (23 19/32" x 23 15/16" x 25 21/64")
Weight(approx.) BP-20M31/20M28: 42 kg (92.6 lbs) BP-20M24/20M22: 34 kg (74.6 lbs)
COPIER (-)
Original size Max. A3 (11" x 17")
First copy time BP-20M31/20M28: 5.2 sec. BP-20M24/20M22: 6.4 sec.
Resolution Scan: 400 x 600 dpi Print: 600 x 600 dpi
Continuous copy Max. 999 copies
Gradation Equivalent to 256 levels
Zoom range 25% to 400% (25% to 200% using RSPF) in 1% increments
Preset copy rations Metric: 10 ratios (5R/5E), inch: 8 ratios (4R/4E)
NETWORK PRINTER (-)
Resolution 600 x 600 dpi
Interface USB 2.0 (host, high-speed), 10Base-T/100Base-TX/1000Base-T, wireless LAN (IEEE 802.11 b/g/n)*10
Network protocols TCP/IP
Printing protocols LPR, Raw TCP (port 9100), FTP for downloading print files, IPP, SMB, WSD
PDL Standard: PCL 6 emulation Option: PostScript® 3™ emulation
Supported OS Windows Server® 2012, Windows Server® 2012 R2, Windows Server® 2016, Windows Server® 2019, Windows® 8.1, Windows® 10, Mac OS 10.9, 10.10, 10.11, 10.12, 10.13, 10.14, 10.15
Available fonts 80 fonts for PCL, 136 fonts for PostScript 3 emulation
Network Scanner (-)
Scan method Push scan (via control panel) Pull scan (TWAIN-compliant application)
Scan speed Colour & B/W: Max. 37 originals/min.
Resolution Push scan: 100, 150, 200, 300, 400, 600 dpi*6 Pull scan: 75, 100, 150, 200, 300, 400, 600 dpi 50 dpi to 9,600 dpi via user setting*7
File formats TIFF, PDF, JPEG*8
Scan destinations Scan to email/desktop*9/FTP server/network folder (SMB)/ USB drive
